Rockwell Automation Publication 2080-UM002G-EN-E - March 2015 31

Install Your Controller Chapter 3

Micro830 24-Point Controllers

2080-LC30-24QWB, 2080-LC30-24QVB, 2080-LC30-24QBB

Micro850 24-Point Controllers

2080-LC50-24AWB, 2080-LC50-24QBB, 2080-LC50-24QVB, 2080-LC50-24QWB

Micro830 48-Point Controllers

2080-LC30-48AWB, 2080-LC30-48QWB, 2080-LC30-48QVB,

2080-LC30-48QBB

45326

100 mm (3.94 in.)

131 mm (5.16 in.)

45913

131 mm (5.16 in.)

100 mm (3.94 in.)
