40 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015

Chapter 4 Wire Your Controller

2080-LC30-10QWB

2080-LC30-10QVB

2080-LC30-16AWB / 2080-LC30-16QWB

TIP

2080-LC30-16AWB has no high-speed inputs.

I-00

COM0 I-01

I-02

I-03

COM1

I-04

I-05 NC

123456789101112

+DC24 CM0

O-00-DC24

CM1

O-01

CM2

O-02 O-03

CM3

123456789101112

45033

Input terminal block

Output terminal block

45034

I-00

COM0 I-01

I-02

I-03

COM1

I-04

I-05 NC

123456789101112

+DC24 +CM0

O-00-DC24

O-01

-CM0

+CM1

O-02 -CM1

O-03

123456789101112

Input terminal block

Output terminal block

45028

I-00

COM0 I-01

I-02

I-03

COM1

I-04

I-05 I-07

I-06

I-09

I-08

123456789101112

+DC24 CM0

O-00-DC24

CM1

O-01

CM2

O-02 O-03

CM3

O-05

O-04

123456789101112

Input terminal block

Output terminal block
