96 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 7 Motion Control

Example: Aborted Movement Function Block During

Acceleration/Deceleration

IMPORTANT

If MC_Halt aborts another movement function block during acceleration

and the MC_Halt Jerk input parameter is less than the Jerk of the

currently executing FB, the Jerk of the currently executing function block

is used to prevent excessively long deceleration.

Velocity

Time

Execute1

Busy

Halt Execute

CommandAborted

46050
