Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 239
Specifications Appendix A
Micro800 Programmable
Controller External AC
Power Supply
General Specifications
Attribute Value
Dimensions (HxWxD) 90 x 45 x 80 mm (3.55 x 1.78 x 3.15 in.)
Shipping weight, approx 0.34 kg (0.75 lb)
Supply voltage range
(1)
(1) Any fluctuation in voltage source must be within 85V...264V. Do not connect the adapter to a power source that
has fluctuations outside of this range.
100V…120V AC, 1 A
200…240V AC, 0.5 A
Supply frequency 47…63 Hz
Supply power 24V DC, 1.6 A
Inrush current, max 24 A @ 132V for 10 ms
40 A @ 263V for 10 ms
Power consumption
(Output power)
38.4 W @ 100V AC,
38.4 W @ 240V AC
Power dissipation
(Input power)
45.1 W @ 100V AC,
44.0 W @ 240V AC
Isolation voltage 250V (continuous), Primary to Secondary: Reinforced Insulation Type
Type tested for 60s @ 2300V AC primary to secondary and 1480V AC
primary to earth ground.
Output ratings, max 24V DC, 1.6 A, 38.4 W
Enclosure type rating Meets IP20
Wire size 0.32...2.1 mm² (22...14 AWG) solid copper wire or
0.32...1.3 mm² (22...16 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Terminal screw torque 0.5…0.6 Nm (4.4…5.3 lb-in.)
(using a Phillips-head or 2.5 mm (0.10in.) flat-blade screwdriver)
Wiring category
(2)
(2) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring
and Grounding Guidelines, publication 1770-4.1
.
2 – on power ports
Insulation stripping length 7 mm (0.28 in.)
North American temp code T4A
