Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 209
Appendix
A
Specifications
Micro830 Controllers
The following tables provide specifications, ratings, and certifications for the
Micro830 controllers.
Micro830 10-Point Controllers
Specifications for the analog and discrete Micro800 plug-in and
expansion I/O modules are available in the following
Rockwell Automation publications:
• Micro800 Expansion I/O Modules User Manual,
publication 2080-UM003
• Micro800 Plug-in Modules User Manual, publication 2080-UM004
At the end of its life, this equipment should be collected separately from any
unsorted municipal waste.
General Specifications
Attribute 2080-LC30-10QWB 2080-LC30-10QVB
Number of I/O 10 (6 inputs, 4 outputs)
Dimensions (HxWxD) 90 x 100 x 80 mm (3.54 x 3.94 x 3.15 in.)
Shipping weight, approx. 0.302 kg (0.666 lb)
Wire size 0.14…2.5 mm
2
(26…14 AWG) solid copper wire or
0.14…1.5 mm
2
(26…16 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use copper conductors only
Terminal screw torque, max 0.6 Nm (4.4 lb-in)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 24V DC sink transistor (standard and high-speed)
Event input interrupt support Yes
Power consumption, max 5 W – without plug-in modules
7.88 W – with plug-in modules
