Appendix A Specifications
Micro830 16-Point Controllers
General Specifications
Attribute 2080-LC30-16AWB 2080-LC30-16QWB 2080-LC30-16QVB
Number of I/O 16 (10 inputs, 6 outputs)
Dimensions (HxWxD) 90 x 100 x 80 mm (3.54 x 3.94 x 3.15 in.)
Shipping weight, approx. 0.302 kg (0.666 lb)
Wire size 0.14…2.5 mm
2
(26…14 AWG) solid copper wire or
0.14…1.5 mm
2
(26…16 AWG) stranded copper wire
rated @ 90 °C (194 °F) insulation max
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type Use Copper Conductors only
Terminal screw torque, max 0.6 Nm (4.4 lb-in.)
(using a 2.5 mm (0.10 in.) flat-blade screwdriver)
Input circuit type 120V AC 12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type Relay 12/24V DC sink transistor (standard
and high-speed)
Event input interrupt support Yes
Power consumption, max 5 W – without plug-in modules
7.88 W – with plug-in modules
Power supply voltage range 20.4…26.4V DC Class 2
I/O rating Input:
120V AC, 16 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
2 A, 240V AC, general use
Input:
24V DC, 8.8 mA
Output:
24V DC, 1 A per point
(Surrounding air temperature 30 °C)
24V DC, 0.3 A per point
(Surrounding air temperature 65 °C)
Isolation voltage 250V (continuous), Reinforced
Insulation Type, Outputs to Aux and
Network, Inputs to Outputs
Type tested for 60 s @ 3250V DC I/O
to Aux and Network, Inputs to Outputs
250V (continuous), Reinforced
Insulation Type, Outputs to Aux and
Network, Inputs to Outputs
Type tested for 60 s @ 720V DC, Inputs
to Aux and Network, 3250V DC
Outputs to Aux and Network, Inputs to
Outputs
50V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs
Type tested for 60s @ 720 V DC, I/O to
Aux and Network, Inputs to Outputs
Pilot duty rating C300, R150 –
Insulation stripping length 7 mm (0.28 in.)
Enclosure type rating Meets IP20
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1.
