Emergency-stop
push button
230V AC
Operation of either of these contacts will
remove power from the external I/O
circuits, stopping machine motion.
Fuse MCR
Fuse
MCR
MCR
MCR
Stop
Start
Line Terminals: Connect to terminals of power
supply
Line Terminals: Connect to 24V DC terminals of
power supply.
230V AC
output
circuits
Disconnect
Isolation
Transformer
115V AC or
230V AC
I/O circuits
L1
L2
Master Control Relay (MCR)
Cat. No. 700-PK400A1
Suppressor
Cat. No. 700-N24
(Lo)
(Hi)
DC Power Supply. Use
NEC Class 2 for UL
Listing
.
X1 X2
115V AC or
230V AC
_
+
MCR
24 V DC
I/O
circuits
Suppr.
Overtravel
limit switch
44565
To Next Page
