Allen-Bradley Micro870

Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 39
Install Your Controller Chapter 3
System Assembly
Micro830, Micro850, and Micro870 24-point Controllers (Front)
Micro830, Micro850, and Micro870 24-point Controllers (Side)
45 145.2
27.8
44.4 14.4
7.2
131
7.8 7.8
7.2
131
22.8
36.6
90
100
110.8
33.8
7.2
Expansion I/O Slots
(Applicable to Micro850 and Micro870 only)
Single-width (1st slot)
Double-width (2nd slot)
2085-ECR (terminator)
Micro830/Micro850/Micro870 24pt Controller
with Micro800 Power Supply
Measurements in millimeters
80
87
Expansion I/O Slots
(Applicable to Micro850 and Micro870 only)
Single-width (1st slot)
Double-width (2nd slot)
2085-ECR (terminator)
Micro830/Micro850/Micro870 24pt Controller
with Micro800 Power Supply
Measurements in millimeters
