Rockwell Automation Publication 2080-UM002K-EN-E - March 2019 189

Using microSD Cards Chapter 10

Figure 3 - Data Log Function Block Timing Diagram

7 DLG_ERR_CFG_FORMAT Data log configuration file format is wrong.

8 DLG_ERR_RTC Real time clock is invalid.

9 DLG_ERR_UNKNOWN Unspecified error has occurred.

IMPORTANT

File access error will be returned during DLG function block execution

when card is full.

DLG Function Block Errors

Status Code Name Description

Disable(0)

Enable(1)

Disable(0)

Enable(1)

Disable(0)

Idle(0)

Busy(1)

Succeed(2)

Idle(0)

Busy(1)

Error(3)

Idle(0)

Enable(1)

Status(0)
