194 Rockwell Automation Publication 2080-UM002K-EN-E - March 2019

Chapter 10 Using microSD Cards

Figure 4 - Recipe Function Block Timing Diagram

12 RCP_ERR_DATAFILE_ABSENT Recipe data file is absent.

13 RCP_ERR_DATAFILE_FORMAT Recipe data file contents are wrong.

14 RCP_ERR_DATAFILE_SIZE Recipe data file size is too big (>4K).

IMPORTANT

File access error will be returned during RCP function block execution

when card is full.

RCP Function Block Errors

Error ID Error name Description

Disable(0)

Enable(1)

Disable(0)

Enable(1)

Disable(0)

Idle(0)

Busy(1)

Succeed(2)

Idle(0)

Busy(1)

Error(3)

Idle(0)

Enable(1)

Status(0)
