Prepare for Installation Chapter 2
Figure 8 - Floor Mount Cabinet Options Bay Access Door
To release or secure door:
• Recommended screwdriver = 9.5 mm (0.375 in.) flat
Floor Mount Frame 8 - IP20, NEMA/UL Type 1 Floor Mount Frame 9 - IP54, NEMA 12
