Allen-Bradley PowerFlex 4M User Manual

1-20 Installation/Wiring
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Accel/Decel Selection
The selection of Accel/Decel rates can be made through digital inputs,
RS485 (DSI) communications and/or parameters.
Jog Input
Enabled and Active:
t201 or t202 = 2
Ye s
A405 [Jog Accel/Decel] used.
P109 [Accel Time 1]/P110 [Decel Time 1]
are used.
RS485 (DSI) Port
Controls Speed
Active when
A401 [Accel Time 2]/A402 [Decel Time 2]
is selected by RS485 (DSI) port.
Input is programmed
as “Accel 2 & Decel 2”
t201 or t202 = 1
A401 [Accel Time 2]/A402 [Decel Time 2]
is active when input is active.
Speed is controlled
by [Preset Freq x]
t201 or t202 = 4
P109 [Accel Time 1]/P110 [Decel Time 1];
A401 [Accel Time 2]/A402 [Decel Time 2]
determined by the active Preset Frequency.
See A410-A413 [Preset Freq 0-3]
on page 3-21
.
No
No
Ye s
Ye s
Ye s
No
No

Allen-Bradley PowerFlex 4M Specifications

General

Input Voltage	200…240V AC, 380…480V AC, 500…600V AC
Output Voltage	0-Input Voltage
Control Method	Sensorless Vector
Communications	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure	IP20
Operating Temperature	-10°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5-95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
