Programming and Parameters 3-3
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Display Group
d001 [Output Freq] Related Parameter(s): d002, d010, P104, P105, P108
Output frequency present at T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0.0/
P105 [Maximum Freq]
Display: 0.1 Hz
d002 [Commanded Freq] Related Parameter(s): d001, d013, P104, P105, P108
Value of the active frequency command. Displays the commanded frequency even if the drive is not
running.
Important: Th
e frequency command can come from a number of sources. Refer to Start and Speed
Reference Control on page 1-19 for details.
Values Default Read Only
Min/Max: 0.0/
P105 [Maximum Freq]
Display: 0.1 Hz
d003 [Output Current]
The output current present at T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0.00/(Drive Rated Amps × 2)
Display: 0.01 Amps
d004 [Output Voltage] Related Parameter(s): P101, A453, A457
Output voltage present at terminals T1, T2 & T3 (U, V & W).
Values Default Read Only
Min/Max: 0/Drive Rated Volts
Display: 0.1 VAC
d005 [DC Bus Voltage]
Present DC bus voltage level.
Values Default Read Only
Min/Max: Based on Drive Rating
Display: 1 VDC
