3-2 Programming and Parameters
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Parameter Organization
Group Parameters
Basic Display Output Freq d001
Commanded Freq d002
Output Current d003
Output Voltage d004
DC Bus Voltage d005
Drive Status d006
Fault 1 Code d007
Fault 2 Code d008
Fault 3 Code d009
Process Display d010
Control Source d012
Contrl In Status d013
Dig In Status d014
Comm Status d015
Control SW Ver d016
Drive Type d017
Elapsed Run Time d018
Testpoint Data d019
Analog In 0-10V d020
Analog In 4-20mA d021
Drive Temp d022
Basic Program Motor NP Volts P101
Motor NP Hertz P102
Motor OL Current P103
Minimum Freq P104
Maximum Freq P105
Start Source P106
Stop Mode P107
Speed Reference P108
Accel Time 1 P109
Decel Time 1 P110
Motor OL Ret P111
Reset To Defalts P112
Terminal Block Digital In1 Sel t201
Digital In2 Sel t202
Analog In 0-10V Lo t211
Analog In 0-10V Hi t212
Analog In 4-20mA Lo d213
Analog In 4-20mA Hi d214
Relay Out Sel t221
Relay Out Level t222
Communications Language C301
Comm Data Rate C302
Comm Node Addr C303
Comm Loss Action C304
Comm Loss Time C305
Comm Format C306
Comm Write Mode C307
Advanced Program Accel Time 2 A401
Decel Time 2 A402
S Curve % A403
Jog Frequency A404
Jog Accel/Decel A405
Internal Freq A409
Preset Freq 0 A410
Preset Freq 1 A411
Preset Freq 2 A412
Preset Freq 3 A413
Skip Frequency A418
Skip Freq Band A419
DC Brake Time A424
DC Brake Level A425
DB Resistor Sel A427
DB Duty Cycle A428
Start At PowerUp A433
Reverse Disable A434
Flying Start En A435
Compensation A436
Slip Hertz @ FLA A437
Process Time Lo A438
Process Time Hi A439
Process Factor A440
Bus Reg Mode A441
Current Limit A442
Motor OL Select A444
PWM Frequency A446
SW Current Trip A448
Fault Clear A450
Auto Rstrt Tries A451
Auto Rstrt Delay A452
Boost Select A453
Maximum Voltage A457
Program Lock A458
Testpoint Sel A459
Motor NP FLA A461
