Allen-Bradley PowerFlex 4M User Manual

B-6 Accessories and Dimensions
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Table B.I PowerFlex 4M Panel Mount Drives – Ratings are in kW and (HP)
Figure B.1 PowerFlex 4M Panel Mount Drives
– Dimensions are in millimeters and (inches). Weights are in kilograms and (pounds).
Product Dimensions
Frame
120V AC – 1-Phase 240V AC – 1-Phase 240V AC – 3-Phase 480V AC – 3-Phase
A 0.2 (0.25)
0.4 (0.5)
0.2 (0.25)
0.4 (0.5)
0.75 (1.0)
0.2 (0.25)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
0.4 (0.5)
0.75 (1.0)
1.5 (2.0)
B 0.75 (1.0)
1.1 (1.5)
1.5 (2.0)
2.2 (3.0)
2.2 (3.0)
3.7 (5.0)
2.2 (3.0)
3.7 (5.0)
C — — 5.5 (7.5)
7.5 (10.0)
5.5 (7.5)
7.5 (10.0)
11.0 (15.0)
a
c
b
d
e
g
h
f
j
i
k*
Note:
DIN rail mounting is not applicable to Frame C.
Frame a b c d e f g h i j k
Shipping
W
eight
A 72.0
(2.83)
59.0
(2.32)
174.0
(6.85)
151.6
(5.97)
5.4
(0.21)
5.4
(0.21)
5.2
(0.20)
—
136.0
(5.35)
90.9
(3.58)
81.3
(3.20)
1.6 (3.5)
B 100
(3.
94)
89.0
(3.50)
174.0
(6.85)
163.5
(6.44)
5.4
(0.21)
5.4
(0.21)
5.2
(0.20)
0.5
(0.02)
136.0
(5.35)
90.9
(3.58)
81.3
(3.20)
2.1 (4.6)
C 130.0
(5.
12)
116.0
(4.57)
260.0
(10.24)
247.5
(9.74)
5.5
(0.22)
5.5
(0.22)
6.0
(0.24)
1.0
(0.04)
180.0
(7.09)
128.7
(5.07)
—
4.8 (10.6)
∅
∅
∅
∅
∅
∅

Allen-Bradley PowerFlex 4M Specifications

General

Input Voltage	200…240V AC, 380…480V AC, 500…600V AC
Output Voltage	0-Input Voltage
Control Method	Sensorless Vector
Communications	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure	IP20
Operating Temperature	-10°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5-95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
