The drive speed command can be obtained from a number of different
sources. The source is normally determined by P108
[Speed Reference].
However, when t201
or t202 Digital Inx Sel is set to option 2, 4, 5 or 6,
and the digital input is active, t201
or t202 will override the speed
reference commanded by P108
[Speed Reference]. See the chart below
for the override priority.
Start and Speed Reference Control
Jog Input
Enabled and Active:
t201 or t202 = 2
Ye s
Drive will Start and Run at Jog Speed.
Direction comes from
Terminal 03 Dir/Run REV
Local/Remote Input
Enabled and Active:
t201 or t202 = 5
Ye s
Start, Speed and Direction commands
come from Integral Keypad.
Comm Select Input
Enabled and Active:
t201 or t202 = 6
Ye s
Start, Speed and Direction commands
come from RS485 (DSI) port.
P108 [Speed Reference]
= 4 or 5
Ye s
Run as specified by
P108 [Speed Reference].
Start and Direction commands come
from P106 [Start Source].
t201 / t202
Preset Inputs Active
Ye s
Run as specified by
A411-A413 [Preset Freq 1-3].
Start and Direction commands come
from P106 [Start Source].
Run as specified by
P108 [Speed Reference].
Start and Direction commands
come from P106 [Start Source].
No
No
No
No
No

Allen-Bradley PowerFlex 4M Specifications

General

Input Voltage	200…240V AC, 380…480V AC, 500…600V AC
Output Voltage	0-Input Voltage
Control Method	Sensorless Vector
Communications	RS-485
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure	IP20
Operating Temperature	-10°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5-95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
