PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Chapter 3
Programming and Parameters
Chapter 3 provides a complete listing and description of the PowerFlex
4M parameters. Parameters are programmed (viewed/edited) using the
integral keypad. As an alternative, programming can also be performed
using DriveExplorer™ or DriveExecutive™ software, a personal
computer and a serial converter module. Refer to
Appendix B for catalog
numbers.
To configure a drive to operate in a specific way, drive parameters may
have to be set. Three types of parameters exist:
• EN
UM
ENUM parameters allow a selection from 2 or more items. Each item
is represented by a number.
• N
umeric Parameters
These parameters have a single numerical value (i.e. 0.1 Volts).
• B
it Parameters
Bit parameters have four individual bi
ts associated with features or
conditions. If the bit is 0, the feature is off or the condition is false. If
the bit is 1, the feature is on or the condition is true.
Some parameters are marked as follows.
For information on… See page…
About Parameters 3-1
Parameter Organization 3-2
Display Group 3-3
Basic Program Group 3-8
Terminal Block Group 3-13
Communications Group 3-17
Advanced Program Group 3-19
Parameter Cross Reference – by Name 3-31
About Parameters
= Stop drive before changing this parameter.
= 32 bit parameter. Parameters marked 32 bit will have two
parameter numbers when using RS485 communications and
programming software.
