Programming and Parameters 3-31
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Parameter Cross Reference – by Name
Parameter Name Number Group Page
Accel Time 1 P109 Basic Program 3-11
Accel Time 2 A401 Advanced Program 3-19
Analog In 0-10V d020 Display 3-7
Analog In 4-20mA d021 Display 3-7
Anlg In 0-10V Hi t212 Terminal Block 3-14
Anlg In 0-10V Lo t211 Terminal Block 3-14
Anlg In4-20mA Hi t214 Terminal Block 3-15
Anlg In4-20mA Lo t213 Terminal Block 3-14
Auto Rstrt Delay A452 Advanced Program 3-28
Auto Rstrt Tries A451 Advanced Program 3-28
Boost Select A453 Advanced Program 3-29
Bus Reg Mode A441 Advanced Program 3-26
Comm Data Rate C302 Communications 3-17
Comm Format C306 Communications 3-18
Comm Loss Action C304 Communications 3-17
Comm Loss Time C305 Communications 3-18
Comm Node Addr C303 Communications 3-17
Comm Status d015 Display 3-6
Comm Write Mode C307 Communications 3-18
Commanded Freq d002 Display 3-3
Compensation A436 Advanced Program 3-25
Contrl In Status d013 Display 3-5
Control Source d012 Display 3-5
Control SW Ver d016 Display 3-6
Current Limit A441 Advanced Program 3-26
DB Duty Cycle A428 Advanced Program 3-24
DB Resistor Sel A427 Advanced Program 3-23
DC Brake Level A425 Advanced Program 3-23
DC Brake Time A424 Advanced Program 3-21
DC Bus Voltage d005 Display 3-3
Decel Time 1 P110 Basic Program 3-12
Decel Time 2 A402 Advanced Program 3-19
Dig In Status d014 Display 3-6
Digital In1 Sel t201 Terminal Block 3-13
Digital In2 Sel t202 Terminal Block 3-13
Drive Status d006 Display 3-4
Drive Temp d022 Display 3-7
Drive Type d017 Display 3-6
Elapsed Run Time d018 Display 3-7
Fault 1 Code d007 Display 3-4
Fault 2 Code d008 Display 3-4
Fault 3 Code d009 Display 3-4
Fault Clear A450 Advanced Program 3-28
Flying Start En A435 Advanced Program 3-24
Internal Freq A409 Advanced Program 3-20
Jog Accel/Decel A405 Advanced Program 3-20
Jog Frequency A404 Advanced Program 3-20
Language C301 Communications 3-17
Maximum Freq P105 Basic Program 3-8
Maximum Voltage A457 Advanced Program 3-30
Minimum Freq P104 Basic Program 3-8
Motor NP FLA A461 Advanced Program 3-30
Motor NP Hertz P102 Basic Program 3-8
Motor NP Volts P101 Basic Program 3-8
Motor OL Current P103 Basic Program 3-8
Motor OL Ret P111 Basic Program 3-12
Motor OL Select A444 Advanced Program 3-26
Output Current d003 Display 3-3
Output Freq d001 Display 3-3
Output Voltage d004 Display 3-3
Preset Freq 0 A410 Advanced Program 3-21
Preset Freq 1 A411 Advanced Program 3-21
Preset Freq 2 A412 Advanced Program 3-21
Preset Freq 3 A413 Advanced Program 3-21
Process Display d010 Display 3-4
Process Factor A440 Advanced Program 3-26
Process Time Hi A439 Advanced Program 3-25
Process Time Lo A438 Advanced Program 3-25
Program Lock A458 Advanced Program 3-30
PWM Frequency A446 Advanced Program 3-27
Relay Out Level t222 Te r mi na l Bl ock 3-16
Relay Out Sel t221 Ter mi na l Bl ock 3-15
Reset To Defalts P112 Basic Program 3-12
Reverse Disable A434 Advanced Program 3-24
S Curve % A403 Advanced Program 3-20
Skip Freq Band A419 Advanced Program 3-22
Skip Frequency A418 Advanced Program 3-21
Slip Hertz @ FLA A437 Advanced Program 3-25
Speed Reference P108 Basic Program 3-11
Start At PowerUp A433 Advanced Program 3-24
Start Source P106 Basic Program 3-9
Stop Mode P107 Basic Program 3-10
SW Current Trip A448 Advanced Program 3-27
Testpoint Data d019 Display 3-7
Testpoint Sel A459 Advanced Program 3-30
