P-2 Overview
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
• In this manual we refer to the PowerFlex 4M Adjustable Frequency
AC Drive as: drive, PowerFlex 4M or PowerFlex 4M Drive.
• P
arameter numbers and names are shown in this format:
• The following words are used throughout the manual to describe an
action:
Similar PowerFlex 4M drive sizes are
grouped into frame sizes to
simplify spare parts ordering, dimensioning, etc. A cross-reference of
drive catalog numbers and their respective frame sizes is provided in
Appendix B.
Manual Conventions
P101 [Motor NP Volts]
Name
Number
Group
d = Display Group
P = Basic Program Group
t = Terminal Block Group
C = Communications Group
A = Advanced Program Group
Word Meaning
Can Possible, able to do something
Cannot Not possible, not able to do something
May Permitted, allowed
Must Unavoidable, you must do this
Shall Required and necessary
Should Recommended
Should Not Not Recommended
Drive Frame Sizes
