Accessories and Dimensions B-5
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Table B.G Human Interface Module (HIM) Option Kits and Accessories
Table B.H Communication Option Kits
Item Description Catalog Number
LCD Display, Remote Panel
M
ount
Digital speed control
CopyCat capable
IP66 (NEMA Type 4X/12) indoor use only
22-HIM-C2 includes 2.9 meter cable.
22-HIM-C2S includes 2 meter cable.
22-HIM-C2
22-HIM-C2S
(1)
(1)
The 22-HIM-C2S is smaller than the 22-HIM-C2 and cannot be used as a direct replacement.
LCD Display, Remote Handheld Digital speed control
Full numeric keypad
CopyCat capable
IP30 (NEMA Type 1)
Includes 1.0 meter cable
Panel mount with optional Bezel Kit
22-HIM-A3
Bezel Kit Panel mount for LCD Display, Remote
Hand
held unit, IP30 (NEMA Type 1)
22-HIM-B1
DSI HIM Cable
(DSI HIM to RJ45 cable)
1.0 Meter (3.3 Feet)
2.9 Meter (9.51 Feet)
22-HIM-H10
22-HIM-H30
Item Description Catalog Number
(2)
(2)
For pricing information, refer to the PowerFlex 4-Class Price List, Publication 22-PL001….
External DSI™
Com
munications Kit
External mounting kit for 22-COMM-C, -D, -E, -P. 22-XCOMM-DC-BASE
External Comms Power
Supply
Optional 100-240V AC Power Supply for External
DSI Com
munications Kit.
20-XCOMM-AC-PS1
Compact I/O Module Three channel. 1769-SM2
Serial Converter Module
(RS485 to RS2
32)
Provides serial communication via DF1 protocol
for use with DriveExplorer and DriveExecutive
software. Includes:
DSI to RS232 serial converter (1)
1203-SFC serial cable (1)
22-RJ45CBL-C20 cable (1)
DriveExplorer Lite CD (1)
22-SCM-232
DSI Cable 2.0 meter RJ45 to RJ45 cable, male to male
connectors
.
22-RJ45CBL-C20
Serial Cable 2.0 meter serial cable with a locking low profile
connector to connect to the ser
ial converter and a
9-pin sub-miniature D female connector to
connect to a computer.
1203-SFC
Null Cable Converter For use when connecting the serial converter to
Dr
iveExplorer on a handheld PC.
1203-SNM
Splitter Cable RJ45 one to two port splitter cable AK-U0-RJ45-SC1
Terminating Resistors RJ45 120 Ohm resistors (2 pieces) AK-U0-RJ45-TR1
Ter mina l B lock RJ45 Two position terminal block (5 pieces) AK-U0-RJ45-TB2P
DriveExplorer Software
(CD-R
OM) Version 3.01
or later
Windows based software package that provides
an intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online.
Compatibility: Windows 95, 98, ME, NT 4.0
(Ser
vice Pack 3 or later), 2000, XP and CE
(1)
(1)
See www.ab.com/drives/driveexplorer.htm for supported devices.
9306-4EXP01ENE
DriveExecutive software
(CD-R
OM) Version 1.01
or later
Windows based software package that provides
an intuitive means for monitoring or configuring
Allen-Bradley drives and communication adapters
online and offline.
Compatibility: Windows 98, ME, NT 4.0 (Service
P
ack 3 or later), 2000 and XP
9303-4DTE01ENE
