A-2 Supplemental Drive Information
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Specifications
Drive Ratings
Catalog
Number
Output Ratings Input Ratings Branch Circuit Protection
kW (HP) Amps
Voltage
Rang
e kVA Amps Fuses
140M Motor
Protectors
(2) (3)
Contactors
Min. Enclosure
Volume
(4)
(in.
3
)
100 - 120V AC (±10%) – 1-Phase Input, 0 - 230V 3-Phase Output
22F-V1P6N103 0.2 (0.25) 1.6 90-126 0.8 6.4 10 140M-C2E-C10 100-C09 1655
22F-V2P5N103 0.4 (0.5) 2.5 90-126 1.1 9.0 15 140M-C2E-C16 100-C12 1655
22F-V4P5N103 0.75 (1.0) 4.5 90-126 2.2 18.0 30 140M-D8E-C20 100-C23 1655
22F-V6P0N103 1.1 (1.5) 6.0 90-126 2.9 24.0 40 140M-F8E-C32 100-C30 1655
200 - 240V AC (±10%) – 1-Phase Input, 0 - 230V 3-Phase Output
22F-A1P6N103 0.2 (0.25) 1.6 180-265 0.7 5.3 10 140M-C2E-B63 100-C09 1655
22F-A2P5N103 0.4 (0.5) 2.5 180-265 1.6 6.5 10 140M-C2E-C10 100-C09 1655
22F-A4P2N103 0.75 (1.0) 4.2 180-265 2.0 8.2 15 140M-C2E-C16 100-C12 1655
22F-A8P0N103 1.5 (2.0) 8.0 180-265 5.4 22.3 35 140M-D8E-C25 100-C23 1655
22F-A011N103 2.2 (3.0) 11.0 180-265 5.9 24.3 40 140M-F8E-C32 100-C30 1655
200 - 240V AC (±10%) – 1-Phase Input, 0 - 230V 3-Phase Output, with Filter
22F-A1P6N113 0.2 (0.25) 1.6 180-265 1.3 5.3 10 140M-C2E-B63 100-C09 1655
22F-A2P5N113 0.4 (0.5) 2.5 180-265 1.6 6.5 10
140M-C2E-C10 100-C09 1655
22F-A4P2N113 0.75 (1.0) 4.2 180-265 2.0 8.2 15 140M-C2E-C16 100-C12 1655
22F-A8P0N113 1.5 (2.0) 8.0 180-265 5.4 22.3 35 140M-D8E-C25 100-C23 1655
22F-A011N113 2.2 (3.0) 11.0 180-265 5.9 24.3 40 140M-F8E-C32 100-C30 1655
200 - 240V AC (±10%) – 3-Phase Input, 0 - 230V 3-Phase Output
22F-B1P6N103 0.2 (0.25) 1.6 180-265 0.8 1.9 3 140M-C2E-B25 100-C09 1655
22F-B2P5N103 0.4 (0.5) 2.5 180-265 1.2 2.7 6 140M-C2E-B40 100-C09 1655
22F-B4P2N103 0.75 (1.0) 4.2 180-265 2.1 4.9 10 140M-C2E-B63 100-C09 1655
22F-B8P0N103 1.5 (2.0) 8.0 180-265 4.0 9.5 15 140M-C2E-C16 100-C12 1655
22F-B012N103 2.2 (3.0) 12.0 180-265 6.3 15.0 25 140M-C2E-C20 100-C23 1655
22F-B017N103 3.7 (5.0) 17.5 180-265 8.8 21.1 35 140M-F8E-C25 100-C23 1655
22F-B025N104
(1)
5.5 (7.5) 25.0 180-265 11.4 27.2 45 140M-F8E-C32 100-C37 3441
22F-B033N104
(1)
7.5 (10.0) 33.0 180-265 16.1 38.5 60 140M-F8E-C45 100-C60 3441
380 - 480V AC (±10%) – 3-Phase Input, 0 - 460V 3-Phase Output
22F-D1P5N103 0.4 (0.5) 1.5 340-528 1.5 1.8 3 140M-C2E-B25 100-C09 1655
22F-D2P5N103 0.75 (1.0) 2.5 340-528 3.0
3.5 6 140M-C2E-B40 100-C09 1655
22F-D4P2N103 1.5 (2.0) 4.2 340-528 5.0 6.0 10 140M-C2E-C10 100-C09 1655
22F-D6P0N103 2.2 (3.0) 6.0 340-528 5.2 6.2 10 140M-C2E-C10 100-C09 1655
22F-D8P7N103 3.7 (5.0) 8.7 340-528 7.0 8.3 15 140M-C2E-C16 100-C12 1655
22F-D013N104
(1)
5.5 (7.5) 13.0 340-528 12.9 15.4 25 140M-D8E-C20 100-C23 3441
22F-D018N104
(1)
7.5 (10.0) 18.0 340-528 16.3 19.5 30 140M-F8E-C25 100-C23 3441
22F-D024N104
(1)
11.0 (15.0) 24.0 340-528 21.7 26.1 40 140M-F8E-C32 100-C30 3441
380 - 480V AC (±10%) – 3-Phase Input, 0 - 460V 3-Phase Output, with Filter
22F-D1P5N113 0.4 (0.5) 1.5 340-528 1.5 1.8 3 140M-C2E-B25 100-C09 1655
22F-D2P5N113 0.75 (1.0) 2.5 340-528 3.0 3.5 6 140M-C2E-B40 100-C09 1655
22F-D4P2N113 1.5 (2.0) 4.2 340-528 5.0 6.0 10 140M-C2E-C10 100-C09 1655
22F-D6P0N113 2.2 (3.0) 6.0 340-528 5.2 6.2 10 140M-C2E-C10 100-C09 1655
22F-D8P7N113 3.7 (5.0) 8.7 340-528 7.0 8.3 15 140M-C2E-C16 100-C12 1655
22F-D013N114
(1)
5.5 (7.5) 13.0 340-528 12.9 15.4 25 140M-D8E-C20 100-C23 3441
22F-D018N114
(1)
7.5 (10.0) 18.0 340-528 16.3 19.5 30 140M-F8E-C25 100-C23 3441
22F-D024N114
(1)
11.0 (15.0) 24.0 340-528 21.7 26.1 40 140M-F8E-C32 100-C30 3441
(1)
Catalog suffix ending with ‘4’, such as N104 and N114, indicate that an internal brake IGBT is supplied.
(2)
The AIC ratings of the Bulletin 140M Motor Protector Circuit Breakers may vary. See Bulletin 140M Motor Protection
Circuit Breakers Application Ratings.
(3)
Manual Self-Protected (Type E) Combination Motor Controller, UL listed for 208 Wye or Delta, 240 Wye or Delta, 480Y/
277 or 600Y/347. Not UL listed for use on 480V or 600V Delta/Delta, corner ground, or high-resistance ground systems.
