B-2 Accessories and Dimensions
PowerFlex 4M Adjustable Frequency Drive FRN 1.xx - 2.xx User Manual
Publication 22F-UM001D-EN-E
Table B.C Dynamic Brake Modules
480V 50/60 Hz
3-Phase
With Integral EMC Filter
(2)
0.4 0.5 1.5
22F-D1P5N113
A
0.75 1.0 2.5
22F-D2P5N113
A
1.5 2.0 4.2
22F-D4P2N113
A
2.2 3.0 6.0
22F-D6P0N113
B
3.7 5.0 8.7
22F-D8P7N113
B
5.5 7.5 13.0
22F-D013N114
(3)
C
7.5 10.0 18.0
22F-D018N114
(3)
C
11.0 15.0 24.0
22F-D024N114
(3)
C
(1)
This filter is suitable for use with a cable length of up to 5 meters (16 feet) for EN55011 class A and
1 meter (3 feet) for EN55011 class B environment.
(2)
This filter is suitable for use with a cable length of up to 10 meters (33 feet) for EN61800-3 Second
environment.
(3)
Catalog suffix ending with ‘4’, such as N104 and N114, indicate that an internal brake IGBT is supplied.
Drive Ratings
Catalog Number
(1)
(2)
(1)
The resistors listed in this table are rated for 5% duty cycle.
(2)
Use of Rockwell resistors is always recommended. The resistors listed have been carefully
selected for optimizing performance in a varity of applications. Alternative resistors may be used,
however care must be taken when making a selection. Refer to the PowerFlex Dynamic Braking
Resistor Calculator, publication PFLEX-AT001….
Input Voltage kW HP
Minimum
Resistance Ω
240V 50/60 Hz
3-Phase
5.5 7.5 18 AK-R2-030P1K2
7.5 10.0 12 AK-R2-030P1K2
480V 50/60 Hz
3-Phase
5.5 7.5 60 AK-R2-120P1K2
7.5 10.0 39 AK-R2-120P1K2
11.0 15.0 36 AK-R2-120P1K2
(3)
(3)
Requires two resistors wired in parallel.
Drive Ratings
Catalog Num
ber
Frame
SizeInput Voltage kW HP
Output
Current (A) Panel Mount
To Next Page
