Connector Descriptions C-5
Table C.E ASIC Board on Power Structure #2 to Gate Driver Board on Power
Structure #2 - Phase V Connections
Note: Refer to footnotes below Table C.F.
Table C.F ASIC Board on Power Structure #2 to Gate Driver Board on Power
Structure #2 - Phase W Connections
ASIC Board
Connector Pin Number to Pin Number
Gate Driver Board
Connector Description
X4 1 . . . 1 X14 V_Feedback
2 . . . 2 V_Power_OK
3 . . . 3 V_DTR
(1)
4 . . . 4 V_ETR
(2)
5 . . . 5 V_ITR
(3)
6 . . . 6 V_DC-
7 . . . 7 VI
8 . . . 8 V_DC-_I
9 . . . 9 V_TEMP
10 . . . 10 V_DC-T
H10 (fiber optic) H10 . . . H6 H6 (fiber optic) VH or Gate Top
H11 (fiber optic) H11 . . . H7 H7 (fiber optic) VL or Gate Bottom
ASIC Board
Connector Pin Number to Pin Number
Gate Driver Board
Connector Description
X5 1 . . . 1 X15 W_Feedback
2 . . . 2 W_Power_OK
3 . . . 3 W_DTR
(1)
(1)
DTR = N Desat
4 . . . 4 W_ETR
(2)
(2)
ETR = Phase I2T
5 . . . 5 W_ITR
(3)
(3)
ITR = Phase Overcurrent
6 . . . 6 W_DC-
7. . . 7 WI
8 . . . 8 W_DC-_I
9 . . . 9 W_TEMP
10 . . . 10 W_DC-T
H12 (fiber optic) H12 . . . H8 H8 (fiber optic) WH or Gate Top
H13 (fiber optic) H13 . . . H9 H9 (fiber optic) WL or Gate Bottom
