Drive Port 0 Parameters Chapter 3
DIAGNOSTICS
Status
Drive Status 1 Bit Descriptions
Bits 10… 14 “SpdRef Bit x” – See Table 935A: Reference Status:
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Table 935A: Reference Status
Bit1413121110Reference Source Parameter
00001Auto, Ref A 545
00010Auto, Ref B 550
00011Auto, Preset 3 573
00100Auto, Preset 4 574
00101Auto, Preset 5 575
00110Auto, Preset 6 576
00111Auto, Preset 7 577
10000MAN, Port 0, DIGIN SEL 563
10001MAN, Port 1 871
10010MAN, Port 2 872
10011MAN, Port 3 873
10100MAN, Port 4 874
10101MAN, Port 5 875
10110MAN, Port 6 876
11101MAN, Port 13 INT. ENET 877
11110MAN, Port 14 DRV LOGIX878
11111ALT MAN REF SEL 328
