168 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
DIAGNOSTICS
Peak Detection
1035 PkDtct Stpt Real
Peak Detection Setpoint Real
A setpoint value, in the form of a real number. Intended to be used as a potential data
source for P1038 [PkDtct1PresetSel] and P1043 [PkDtct2PresetSel].
Default:
Min/Max:
0.000000
–/+ 220000000.000000
RW Real
1036 PkDtct Stpt DInt
Peak Detection Setpoint D Integer
A setpoint value, in the form of an integer number. Intended to be used as a potential
data source for P1038 [PkDtct1PresetSel] and P1043 [PkDtct2PresetSel].
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
1037 PkDtct1 In Sel
Peak Detection 1 Input Select
Selects the input data source for the peak detect functions. The functions can be
configured to sample and hold either the largest (maximum) or smallest (minimum)
value of the input signal selected by this parameter.
Important: Either real or integer data sources can be selected, but integer sources will
be internally converted to real and displayed in the peak detect output as real numbers.
Default:
Min/Max:
1035
0 / 15999931
RW 32-bit
Integer
1038 PkDtct1PresetSel
Peak Detection 1 Preset Select
Selects the preset data source for the peak detect functions. The output of the each peak
detect function can be forced to equal the value of the input signal selected by this
parameter by using the”Peak1 Set” bit in P1039 [Peak1 Cfg]. The same integer to real
number conversion applies to both the input and the preset signal.
Default:
Min/Max:
0
0 / 15999931
RW 32-bit
Integer
