Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 167
Drive Port 0 Parameters Chapter 3
DIAGNOSTICS
Fault/Alarm Info
964 CRC Flt Cfg
CRC Fault Configuration
Allows the user to configure exception 917 [FPGA CRC Failure] and change the default
state.
Ignore (0) – No action is taken.
Alarm (1) – Type 1 alarm indicated.
Flt Minor (2) – Minor fault indicated. If running, drive continues to run.
Enable with P950 [Minor Flt Cfg]. If not enabled, acts like a major fault.
FltCoastStop (3) – Major fault indicated. Coast to Stop.
Flt RampStop (4) – Major fault indicated. Ramp to Stop.
Flt CL Stop (5) – Major fault indicated. Current Limit Stop.
FltNonReset (6) – Major fault indicated. Cycle power to clear this fault.
Default:
Options:
6 - FltNonReset
0 - Ignore
1 - Alarm
2 - Fit Minor
3 - FltCoastStop
4 - Flt RampStop
5 - Flt CL Stop
6 - FltNonReset
RW 32-bit
Integer
753
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
DIAGNOSTICS
Testpoints
970
974
978
982
Testpoint Sel 1
Testpoint Sel 2
Testpoint Sel 3
Testpoint Sel 4
Testpoint Select n
Selects a source for the testpoint values (“Fval” and “Lval”). Used by the factory, typically
for diagnostic purposes.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
971
975
979
983
Testpoint Fval 1
Testpoint Fval 2
Testpoint Fval 3
Testpoint Fval 4
Testpoint Float Value n
Displays data selected by [Testpoint Sel n], if the data type is floating point.
Default:
Min/Max:
0.000000
–/+ 220000000.000000
RW Real
972
976
980
984
Testpoint Lval 1
Testpoint Lval 2
Testpoint Lval 3
Testpoint Lval 4
Testpoint Long Value n
Displays data selected by [Testpoint Sel n], if the data type is long integer.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
