Allen-Bradley PowerFlex 750 Series Programming Manual

178 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
APPLICATIONS
Fibers Function
1126 P Jump
Position Jump
Sets the amplitude of the square wave speed modulation for the Fiber Traverse function.
This speed is alternately added to and subtracted from the speed reference together
with the P1125 [Max Traverse] triangle speed modulation.
Units:
Default:
Min/Max:
Hz
RPM
0.00
0.00 / P520 [Max Fwd Speed]
RW Real
1129 DI Fiber SyncEna
Digital Input Fiber Synchronize Enable
Selects a digital input source for the Fiber Application Function's synchronous speed
change routine. Used in combination with the P1120 [Fiber Control] Sync Enable bit.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
1130 DI Fiber TravDis
Digital Input Fiber Traverse Disable
Selects a digital input source for the Fiber Application Traverse Routine. This is an
inverted input, so the Traverse Routine is disabled when the input is active (set). Used in
combination with P1120 [Fiber Control] Bit 1 “Traverse Ena.”
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
APPLICATIONS
Adjustable Vltg
1131 Adj Vltg Config
Adjustable Voltage Configuration
RW 16-bit
Integer
Selects output voltage phase setting. Single-phase operation is intended for resistive loads such as heating coils.
Connect single-phase loads across the U/T1 and V/T2 output terminals.
1133 Adj Vltg Select
Adjustable Voltage Reference Select
Selects the source of the voltage reference to the drive.
Default:
Min/Max:
0
0 / 159999
RW 32-bit
Integer
1134 Adj Vltg Ref Hi
Adjustable Voltage Reference High
Scales the upper value of the P1133 [Adj Vltg Select] selection when the source is an
analog input.
Units:
Default:
Min/Max:
%
0.0
0 / 100.0 of Drive Rated Volts
RW Real
1135 Adj Vltg Ref Lo
Adjustable Voltage Reference Low
Scales the lower value of the P1133 [Adj Vltg Select] selection when the source is an
analog input.
Units:
Default:
Min/Max:
%
0.0
0 / 100.0 of Drive Rated Volts
RW Real
1136 Adj Vltg TrimSel
Adjustable Voltage Trim Select
Selects the source of the voltage trim that is added to or subtracted from the voltage
reference.
Default:
Min/Max:
0
0 / 159999
RW 32-bit
Integer
1137 Adj Vltg Trim Hi
Adjustable Voltage Trim High
Scales the upper value of the P1136 [Adj Vltg TrimSel] selection when the source is an
analog input.
Units:
Default:
Min/Max:
%
0.0
0 / 100.0 of Drive Rated Volts
RW Real
1138 Adj Vltg Trim Lo
Adjustable Voltage Trim Low
Scales the lower value of the P1136 [Adj Vltg TrimSel] selection when the source is an
analog input.
Units:
Default:
Min/Max:
%
0.0
0 / 100.0 of Drive Rated Volts
RW Real
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved PhaseSetting
Default0000000000000001
Bit 1514131211109876543210
0 = 3-Phase Operation
1 = 1-Phase Operation
