Allen-Bradley PowerFlex 750 Series Programming Manual

180 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
APPLICATIONS
Pump Jack
1165 Rod Speed
Rod Speed
Displays the speed in RPM of the pump rod after the gearbox and sheaves.
Rod Speed = Motor Speed x P1174 [Total Gear Ratio]
Units:
Default:
Min/Max:
RPM
0.00
0.00 / 10000.00
RO Real
1166 Rod Torque
Rod Torque
Displays the load side torque. P1174 [Total Gear Ratio] must be greater than zero to
activate this display.
Units:
Default:
Min/Max:
FtLb
0.00
0.00 / 10000.00
RO Real
1167 Rod Speed Cmd
Rod Speed Command
Displays the commanded speed in RPM of the pump rod after the gearbox and sheaves.
Units:
Default:
Min/Max:
RPM
0.00
0.00 / 10000.00
RO Real
1168 TorqAlarm Action
Torque Alarm Action
Sets the drive action when the Torque Alarm is exceeded. Note: only active with PC
pump applications. See P1179 [OilWell Pump Cfg].
Default:
Options:
0 = “Ignore”
0 = “Ignore”
1 = “Preset Spd1”
RW 32-bit
Integer
1169 TorqAlarm Config
Torque Alarm Configure
RW 16-bit
Integer
Enables the Torque Alarm function.
1170 TorqAlarm Dwell
Torque Alarm Dwell
Sets the time that the torque must exceed P1171 [TorqAlarm Level] before P1168
[TorqAlarm Action] takes place.
Active when P1169 [TorqAlarm Config] Bit 0 “Torque Level” = 1 (enabled).
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 60.0
RW Real
1171 TorqAlarm Level
Torque Alarm Level
Sets the level at which the Torque Alarm becomes active.
Active when P1169 [TorqAlarm Config] Bit 0 “Torque Level” = 1 (enabled)
Units:
Default:
Min/Max:
FtLb
0.0
0.0 / 5000.0
RW Real
1172 TorqAlm Timeout
Torque Alarm Time Out
Sets the amount of time a Torque Alarm can be active until timeout action begins.
Active when P1169 [TorqAlarm Config] Bit 0 “Torque Level” = 1 (enabled)
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
1173 TorqAlarm TOActn
Torque Alarm Time Out Action
Sets the drive action when P1172 [TorqAlrm Timeout] is exceeded.
Active when P1169 [TorqAlarm Config] Bit 0 “Torque Level” = 1 (enabled)
“Ignore” (0) – No action is taken.
“Alarm” (1) – Type 1 alarm indicated.
“Flt Minor” (2) – Minor fault indicated. If running, drive continues to run.
Enable with P950 [Minor Flt Cfg]. If not enabled, acts like a major fault.
“FltCoastStop” (3) – Major fault indicated. Coast to Stop.
“Flt RampStop” (4) – Major fault indicated. Ramp to Stop.
“Flt CL Stop” (5) – Major fault indicated. Current Limit Stop.
Default:
Options:
0 = “Ignore”
0 = “Ignore”
1 = “Alarm”
2 = “Flt Minor”
3 = “FltCoastStop”
4 = “Flt RampStop”
5 = “Flt CL Stop”
6 = “Resume”
RW 32-bit
Integer
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Torque Level
Default0000000000000000
Bit 1514131211109876543210
0 = Disabled
1 = Enabled
