Rockwell Automation Publication 750-PM001N-EN-P - February 2017 181
Drive Port 0 Parameters Chapter 3
APPLICATIONS
Pump Jack
1174 Total Gear Ratio
Total Gear Ratio
Displays the calculated total gear ratio as follows:
(P1184 [Gearbox Sheave] x P1183 [Gearbox Ratio]) / P1178 [Motor Sheave]
Default:
Min/Max:
0.0
0.0 / 32000.0
RO Real
1175 Max Rod Speed
Maximum Rod Speed
Sets the maximum speed for the polished rod in a PCP oil well application.
Units:
Default:
Min/Max:
RPM
300.0
200.0 / 600.0
RW Real
1176 Max Rod Torque
Maximum Rod Torque
Sets the desired maximum torque on the polished rod in a PCP oil well application.
Units:
Default:
Min/Max:
FtLb
500.0
0.0 / 3000.0
RW Real
1177 Min Rod Speed
Minimum Rod Speed
Sets the minimum speed for the polished rod in a PCP oil well application.
Units:
Default:
Min/Max:
RPM
0.0
0.0 / 199.0
RW Real
1178 Motor Sheave
Motor Sheave
Sets the sheave diameter on the motor.
Units:
Default:
Min/Max:
Inch
10.0
0.25 / 25.00
RW Real
1179 OilWell Pump Cfg
Oil Well Pump Configure
Selects the type of oil well application.
“Disable” (0) – Disables oil well parameters.
“Pump Jack” (1) – Sets parameters based on Pump Jack type oil well.
“PrgrsvCavity” (2) – Sets parameters based on Progressive Cavity type Pumps.
Default:
Options:
0 = “Disable”
0 = “Disable”
1 = “Pump Jack”
2 = “PrgrsvCavity”
RW 32-bit
Integer
1180 PCP Pump Sheave
PCP Pump Sheave
Specifies the pump sheave diameter.
Units:
Default:
Min/Max:
Inch
20.0
0.25 / 200.00
RW Real
1181 Gearbox Limit
Gearbox Limit
Sets the gearbox torque limit. This value is used in determining the P670 [Pos Torque
Limit] and P671 [Neg Torque Limit].
Units:
Default:
Min/Max:
%
100.0
0.0 / 200.0
RW Real
1182 Gearbox Rating
Gearbox Rating
Sets the gearbox rating.
Units:
Default:
Min/Max:
Kin#
640.0
16.0 / 2560.0
RW Real
1183 Gearbox Ratio
Gearbox Ratio
Specifies the nameplate gear ratio.
Default:
Min/Max:
1.0
1.0 / 40.0
RW Real
1184 Gearbox Sheave
Gearbox Sheave
Sets the Sheave diameter on the Gearbox
Units:
Default:
Min/Max:
Inch
0.25
0.25 / 100.00
RW Real
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
