Rockwell Automation Publication 750-PM001N-EN-P - February 2017 211
Chapter 4
Port 10 and Port 11 Parameters
This chapter lists and describes the PowerFlex 750-Series Port 10 and 11 drive
parameters. The parameters can be programmed (viewed/edited) using a Human
Interface Module (HIM). Refer to Enhanced PowerFlex 7-Class Human
Interface Module (HIM) User Manual, publication 20HIM-UM001
, for
information on using the HIM to view and edit parameters. As an alternative,
programming can also be performed using DriveTools™ software and a personal
computer.
Topic Page
Inverter (Port 10) Common Parameters 212
Inverter n (Port 10) Parameters 214
Converter (Port 11) Common Parameters 217
Converter n (Port 11) Parameters 220
Precharge (Port 11) Common Parameters 223
Precharge n (Port 11) Parameters 225
