Allen-Bradley PowerFlex 750 Series Programming Manual

210 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 3 Drive Port 0 Parameters
APPLICATIONS
Id Compensation
1623 Id Comp Regen 6
Id Compensation Regen 6
Sets Id compensation value (in p.u.) at Iq = P1624 [IdCompRegen 6 Iq] (in p.u.) for
regenerative operation. Id compensation = Id Comp Regen 5 + (Id Comp Regen 6 – Id
Comp Regen 5) x (IqCmd - IdCompRegen 5 Iq) x 1/(IdCompRegen 6 Iq – IdCompRegen 5
Iq) for IqCmd = between IdCompRegen 5 Iq and IdCompRegen 6 Iq.
This parameter is active only in motor control mode flux vector induction (P35 [Motor
Ctrl Mode] = 3 “Induction FV”).
Default:
Min/Max:
0.0000
–/+1.0000
RW Real
1624 IdCompRegen 6 Iq
Id Compensation Regen 6 Iq
Sets Iq value (in p.u.) at which P1623 [Id Comp Regen 6] (in p.u.) is specified.
This parameter is active only in motor control mode flux vector induction (P35 [Motor
Ctrl Mode] = 3 “Induction FV”).
Default:
Min/Max:
1.5000
0.0000 / 5.0000
RW Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755
755
1629 See page 63 for parameter numbers 1629 and 1637…1645.
1630 See page 60
for parameter numbers 1630…1636, 1646, and 1647.
1648 See page 54
for parameter numbers 1648…1661
1700 See page 151 for parameter numbers 1700…1731.
1800 See page 151
for parameter numbers 1800…1831.
1900 See page 151
for parameter numbers 1900, 1904, 1908, 1912, 1916, 1920, 1924, and 1928.
1901 See page 151 for parameter numbers 1901, 1905, 1909, 1913, 1917, 1921, 1925, and 1929.
1902 See page 151
for parameter numbers 1902, 1906, 1910, 1914, 1918, 1922, 1926, and 1930.
1903 See page 151
for parameter numbers 1903, 1907, 1911, 1915, 1919, 1923, 1927, and 1931.
