Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 25
Parameter Organization Chapter 2
Drive Cfg Preferences Speed Units 300 Access Level 301 Language 302
Control Cfg Voltage Class 305
Duty Rating 306
Direction Mode 308
SpdTrqPsn Mode A 309
SpdTrqPsn Mode B 310
SpdTrqPsn Mode C 311
SpdTrqPsn Mode D 312
Actv SpTqPs Mode 313
SLAT Err Stpt 314
SLAT Dwell Time 315
Prchrg Control 321
Prchrg Delay 322
Prchrg Err Cfg 323
Auto Manual Ctrl Logic Mask 324
Auto Mask 325
Manual Cmd Mask 326
Manual Ref Mask 327
Alt Man Ref Sel 328
Alt Man Ref AnHi 329
Alt Man Ref AnLo 330
Manual Preload 331
Drive Memory Reset Meters 336
Start Features Start At PowerUp 345
PowerUp Delay 346
Auto Retry Fault 347
Auto Rstrt Tries 348
Auto Rstrt Delay 349
Sleep Wake Mode 350
SleepWake RefSel 351
Sleep Level 352
Sleep Time 353
Wake Level 354
Wake Time 355
FlyingStart Mode 356
FS Brk Lvl 365
FS Brk Time 366
FS ZSpd Thresh 367
Braking Features Stop Mode A 370
Stop Mode B 371
Bus Reg Mode A 372
Bus Reg Mode B 373
Bus Reg Lvl Cfg 374
Bus Reg Level 375
DB Resistor Type 382
DB Ext Ohms 383
DB Ext Watts 384
DB ExtPulseWatts 385
Flux Braking En 388
Flux Braking Lmt 389
Stop Dwell Time 392
DC Brake Lvl Sel 393
DC Brake Level 394
DC Brake Time 395
Brake Off Adj 1 402
Brake Off Adj 2 403
Dec Inhibit Actn 409
Protection Motor Overload Motor OL Actn 410
Mtr OL at Pwr Up 411
Mtr OL Alarm Lvl 412
Mtr OL Factor 413
Mtr OL Hertz 414
Mtr OL Reset Lvl 415
MtrOL Reset Time 416
Mtr OL Counts 418
Mtr OL Trip Time 419
Load Limits Drive OL Mode 420
Current Lmt Sel 421
Current Limit 1 422
Current Limit 2 423
Active Cur Lmt 424
Current Rate Lmt 425
Regen Power Lmt 426
Motor Power Lmt 427
Shear Pin Cfg 434
Shear Pin 1 Actn 435
Shear Pin1 Level 436
Shear Pin 1 Time 437
Shear Pin 2 Actn 438
Shear Pin2 Level 439
Shear Pin 2 Time 440
Load Loss Action 441
Load Loss Level 442
Load Loss Time 443
OutPhaseLossActn 444
Out PhaseLossLvl 445
Power Loss Power Loss Actn 449
Pwr Loss Mode A 450
Pwr Loss A Level 451
Pwr Loss A Time 452
Pwr Loss Mode B 453
Pwr Loss B Level 454
Pwr Loss B Time 455
UnderVltg Action 460
UnderVltg Level 461
InPhase LossActn 462
InPhase Loss Lvl 463
DC Bus Mem Reset 464
Ground Fault Ground Warn Actn 466 Ground Warn Lvl 467
Predictive Main PredMaint Sts 469
PredMaintAmbTemp 470
PredMaint Rst En 471
PredMaint Reset 472
CbFan Derate
755 (8+)
481
CbFan TotalLife
755 (8+)
482
CbFan ElpsdLife
755 (8+)
483
CbFan RemainLife
755 (8+)
484
CbFan EventLevel
755 (8+)
485
CbFan EventActn
755 (8+)
486
HSFan Derate 488
HSFan TotalLife 489
HSFan ElpsdLife 490
HSFan RemainLife 491
HSFan EventLevel 492
HSFan EventActn 493
HSFan ResetLog
(1)
494
InFan Derate 495
InFan TotalLife 496
InFan ElpsdLife 497
InFan RemainLife 498
(1)
755 Frames 1…7 only.
InFan EventLevel 499
InFan EventActn 500
InFan ResetLog 501
MtrBrngTotalLife 502
MtrBrngElpsdLife 503
MtrBrngRemainLif 504
MtrBrngEventLvl 505
MtrBrngEventActn 506
MtrBrng ResetLog 507
MtrLubeElpsdHrs 508
MtrLubeEventLvl 509
MtrLubeEventActn 510
MchBrngTotalLife 511
MchBrngElpsdLife 512
MchBrngRemainLif 513
MchBrngEventLvl 514
MchBrngEventActn 515
MchBrngResetLog 516
MchLubeElpsdHrs 517
MchLube EventLvl 518
MchLubeEventActn 519
File Group Parameters
Drive Cong
Protection
