Rockwell Automation Publication 750-PM001N-EN-P - February 2017 255
Embedded Feature and Option Module Parameters Chapter 5
22-Series I/O
Digital Outputs
25 RO1 Off Time
Relay Output 1 Off Time – 22-Series I/O Module model 20-750-2262C-2R or 20-750-
2262D-2R is installed.
TO0 Off Time
Transistor Output 0 Off Time – 22-Series I/O Module model 20-750-2263C-1R2T is
installed.
Sets the “OFF Delay” time for the digital outputs. This is the time between the
disappearance of a condition and de-activation of the relay or transistor.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
30 TO1 Sel
Transistor Output 1 Select
Selects the source that will energize the transistor output.
Any status parameter bit can be used as an output source. For example P935 [Drive
Status 1] Bit 7 “Faulted.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
Default:
Min/Max:
0 (Disabled)
0 / 159999.15
RW 32-bit
Integer
31 TO1 Level Sel
Transistor Output 1 Level Select
Selects the source of the level that will be compared.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
Default:
Min/Max:
0 (Disabled)
0 / 159999.15
RW 32-bit
Integer
32 TO1 Level
Transistor Output 1 Level
Sets the level compare value.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
Default:
Min/Max:
0.0
–/+1000000.0
RW Real
33 TO1 Level CmpSts
Transistor Output 1 Level Compare Status
RO 16-bit
Integer
Status of the level compare, and a possible source for a transistor output. Transistor Output n Select must have this selected to energize the output. Can be used
without a physical output as status information only.
Bit 0 “Less Than” – Level source is less than the level value.
Bit 1 “Grt Than Equ” – Level source is greater than or equal to the level value.
Bit 2 “Abs Less Than” – Absolute value of the level source is less than the absolute value of the level value.
Bit 3 “AbsGrtThanEq” – Absolute value of the level source is greater than or equal to the absolute value of the level value.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
34 TO1 On Time
Transistor Output 1 On Time
Sets the “ON Delay” time for the digital outputs. This is the time between the occurrence
of a condition and activation of the transistor.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
35 TO1 Off Time
Transistor Output 1 Off Time
Sets the “OFF Delay” time for the digital outputs. This is the time between the
disappearance of a condition and de-activation of the transistor.
Important: Only used by 22-Series I/O Module model 20-750-2263C-1R2T.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
AbsGrtThanEq
Abs Less Than
Grt Than Equ
Less Than
Default0000000000000000
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
