Allen-Bradley PowerFlex 750 Series Programming Manual

254 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
22-Series I/O
Digital Outputs
14 RO0 On Time
Relay Output 0 On Time
Sets the “ON Delay” time for the digital outputs. This is the time between the occurrence
of a condition and activation of the relay.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
15 RO0 Off Time
Relay Output 0 Off Time
Sets the “OFF Delay” time for the digital outputs. This is the time between the
disappearance of a condition and de-activation of the relay.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
20 RO1 Sel
Relay Output 1 Select – 22-Series I/O Module model 20-750-2262C-2R or 20-750-
2262D-2R is installed.
TO0 Sel
Transistor Output 0 Select – 22-Series I/O Module model 20-750-2263C-1R2T is
installed.
Selects the source that will energize the relay or transistor output.
Any status parameter bit can be used as an output source. For example P935 [Drive
Status 1] Bit 7 “Faulted.”
Default:
Min/Max:
0.00 (Disabled)
0.00 / 159999.15
RW 32-bit
Integer
21 RO1 Level Sel
Relay Output 1 Level Select – 22-Series I/O Module model 20-750-2262C-2R or 20-750-
2262D-2R is installed.
TO0 Level Sel
Transistor Output 0 Level Select – 22-Series I/O Module model 20-750-2263C-1R2T is
installed.
Selects the source of the level that will be compared.
Default:
Min/Max:
0 (Disabled)
0 / 159999
RW 32-bit
Integer
22 RO1 Level
Relay Output 1 Level – 22-Series I/O Module model 20-750-2262C-2R or 20-750-2262D-
2R is installed.
TO0 Level
Transistor Output 0 Level – 22-Series I/O Module model 20-750-2263C-1R2T is installed.
Sets the level compare value.
Default:
Min/Max:
0.0
–/+1000000.0
RW Real
23 RO1 Level CmpSts
Relay Output 1 Level Compare Status – 22-Series I/O Module model 20-750-2262C-2R or 20-750-2262D-2R is installed.
RO 16-bit
Integer
TO0 Level CmpSts
Transistor Output 0 Level Compare Status – 22-Series I/O Module model 20-750-2263C-1R2T is installed.
Status of the level compare, and a possible source for a relay or transistor output. Relay Output n Select or Transistor Output n Select must have this selected to
energize the output. Can be used without a physical output as status information only.
Bit 0 “Less Than” – Level source is less than the level value.
Bit 1 “Grt Than Equ” – Level source is greater than or equal to the level value.
Bit 2 “Abs Less Than” – Absolute value of the level source is less than the absolute value of the level value.
Bit 3 “AbsGrtThanEq” – Absolute value of the level source is greater than or equal to the absolute value of the level value.
24 RO1 On Time
Relay Output 1 On Time – 22-Series I/O Module model 20-750-2262C-2R or 20-750-
2262D-2R is installed.
TO0 On Time
Transistor Output 0 On Time – 22-Series I/O Module model 20-750-2263C-1R2T is
installed.
Sets the “ON Delay” time for the digital outputs. This is the time between the occurrence
of a condition and activation of the relay or transistor.
Units:
Default:
Min/Max:
Secs
0.0
0.0 / 600.0
RW Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved AbsGrtThanEq Abs Less Than Grt Than Equ Less Than
Default0000000000000000
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
