Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 259
Embedded Feature and Option Module Parameters Chapter 5
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
22-Series I/O
Analog Outputs
70 Anlg Out Type
Analog Output Type
RW 16-bit
Integer
Select the analog output mode for each analog output.
71 Anlg Out Abs
Analog Output Absolute
RW 16-bit
Integer
Selects whether the signed value or absolute value of a parameter is used before being scaled to drive the analog output.
75 Anlg Out0 Sel
Analog Output 0 Select
Selects the source for the analog output.
Default:
Min/Max:
3
0 / 159999
RW 32-bit
Integer
76 Anlg Out0 Stpt
Analog Output 0 Setpoint
A possible source for an analog output. Can be used to control an analog output from a
communication device using a DataLink. Not affected by analog output scaling.
Units:
Default:
Min/Max:
Volt
mA
10.000 Volts
20.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
77 Anlg Out0 Data
Analog Output 0 Data
Displays the value of the source selected by P75 [Anlg Out0 Sel].
Default:
Min/Max:
0
–/+40000.000
RO Real
78 Anlg Out0 DataHi
Analog Output 0 Data High
Sets the high value for the data range of analog out scale.
Units:
Default:
Min/Max:
pu
1
–/+40000.000
RW Real
79 Anlg Out0 DataLo
Analog Output 0 Data Low
Sets the low value for the data range of analog out scale.
Default:
Min/Max:
1
–/+40000.000
RW Real
80 Anlg Out0 Hi
Analog Output 0 High
Sets the high value for the analog output value when the data value is at its maximum.
Units:
Default:
Min/Max:
Volt
mA
10.000 Volts
20.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
81 Anlg Out0 Lo
Analog Output 0 Low
Sets the low value for the analog output value when the data value is at its minimum.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog 1 Analog 0
Default0000000000000000
Bit 1514131211109876543210
0 = Voltage Mode
1 = Current Mode
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog 1 Analog 0
Default0000000000000011
Bit 1514131211109876543210
0 = Condition False
1 = Condition True
