260 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
22-Series I/O
Analog Outputs
82 Anlg Out0 Val
Analog Output 0 Value
Displays the analog output value.
Units:
Default:
Min/Max:
Volt
mA
10.000 Volts
20.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RO Real
85 Anlg Out1 Sel
Analog Output 1 Select
Selects the source for the analog output.
Default:
Min/Max:
7
0 / 159999
RW 32-bit
Integer
86 Anlg Out1 Stpt
Analog Output 1 Setpoint
A possible source for an analog output. Can be used to control an analog output from a
communication device using a DataLink. Not affected by analog output scaling.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
87 Anlg Out1 Data
Analog Output 1 Data
Displays the value of the source selected by P85 [Anlg Out1 Sel].
Default:
Min/Max:
0.000
0.000 / 4140.00
RO Real
88 Anlg Out1 DataHi
Analog Output 1 Data High
Sets the high value for the data range of analog out scale.
Default:
Min/Max:
1.000
0.000 / 4140.00
RW Real
89 Anlg Out1 DataLo
Analog Output 1 Data Low
Sets the low value for the data range of analog out scale.
Default:
Min/Max:
0.000
0.000 / 4140.00
RW Real
90 Anlg Out1 Hi
Analog Output 1 High
Sets the high value for the analog output value when the data value is at its maximum.
Units:
Default:
Min/Max:
Volt
mA
10.000 Volts
20.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
91 Anlg Out1 Lo
Analog Output 1 Low
Sets the low value for the analog output value when the data value is at its minimum.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RW Real
92 Anlg Out1 Val
Analog Output 1 Value
Displays the analog output value.
Units:
Default:
Min/Max:
Volt
mA
0.000 Volts
0.000 mA
–/+10.000 Volts
0.000 / 20.000 mA
RO Real
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
