Rockwell Automation Publication 750-PM001N-EN-P - February 2017 85
Drive Port 0 Parameters Chapter 3
DRIVE CFG
Auto Manual Ctrl
329 Alt Man Ref AnHi
Alternate Manual Reference Analog High
Hi scale for the alternate manual speed reference when P328 [Alt Man Ref Sel] is
connected to an Analog Input.
Units:
Default:
Min/Max:
Hz
RPM
P520
P521 / P520
RW Real
330 Alt Man Ref AnLo
Alternate Manual Reference Analog Low
Lo scale for the alternate manual speed reference when P328 [Alt Man Ref Sel] is
connected to an Analog Input.
Units:
Default:
Min/Max:
Hz
RPM
0
P521 / P520
RW Real
331 Manual Preload
Manual Preload
RW 16-bit
Integer
Enables/disables automatic preloading of the “Auto” speed reference into a HIM when the HIM has been granted Manual control while in Auto mode. See P935
[Drive Status 1] Bit 9 “Manual” to verify the operating condition of the drive. Important: Preload will only occur if the transfer from auto to manual is done while
the drive is running.
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
Options
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Port 3
Port 2
Port 1
Reserved
Default0000000000000000
Bit 1514131211109876543210
0 = Disabled
1 = Enabled
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
DRIVE CFG
Drive Memory
336 Reset Meters
Reset Meters
Resets selected meters to zero. The value will automatically be returned to 0.
“MWH and kWh” (1) – Resets P13 [Elapsed MWH], P14 [Elapsed kWH], P16 [Elpsd Mtr
MWHrs], P17 [Elpsd Rgn MWHrs], P18 [Elpsd Mtr kWHrs], and P19 [Elpsd Rgn kWHrs].
“Elapsed Time” (2) – Resets P15 [Elapsed Run Time].
Default:
Options:
0 = “Ready”
0 = “Ready”
1 = “MWH and kWh”
2 = “Elapsed Time”
RW 32-bit
Integer
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
DRIVE CFG
Start Features
345 Start At PowerUp
Start At Power Up
Enables/disables a feature to issue a Run command and automatically resume running
at commanded speed after drive input power is restored. Requires a digital input, P163
[DI Run], P164 [DI Run Forward], or P165 [DI Run Reverse], is configured for Run and a
valid start contact.
Default:
Options:
0 = “Disabled”
0 = “Disabled”
1 = “Enabled”
RW 32-bit
Integer
346 PowerUp Delay
Power Up Delay
Defines the programmed delay time, in seconds, before a start command is accepted
after power up.
Units:
Default:
Min/Max:
Secs
0.00
0.00 / 10800.00
RW Real
ATTENTION: Equipment damage and/or personal injury may result if this parameter is used in an inappropriate
application. Do not use this function without considering applicable local, national and international codes, standards,
regulations or industry guidelines.
