Page #128 background image
Chapter 3
Interpret the Attribute Tables
128 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access
Rule
Attribute B E F P V T Conditional Implementation
445 Set Position Error Tolerance Time
- - Y - -
365 Get Position Fine Command
- - Y - -
446 Set Position Integrator Control
- - R - - O-Bit
1: Auto-Preset (N)
447 Set Position Integrator Preload
- - N - -
781 Set Position Lead Lag Filter Bandwidth
- - Y - -
782 Set Position Lead Lag Filter Gain
- - Y - -
783 Set Position Notch Filter Frequency
- - N - -
627 Set Power Loss Action
- N N N N O-Enum
2 = Decel Regen (N)
628 Set Power Loss Threshold N - N N N N
630 Set Power Loss Time N - N N N N
590 Set Proving Configuration
- Y5 Y Y Y V26/V27
376 Set* Ramp Acceleration
- N - N - Derived
377 Set* Ramp Deceleration
- N - N - Derived
378 Set Ramp Jerk Control
- N - N -
375 Set* Ramp Velocity - Negative
- N - N - Derived
374 Set* Ramp Velocity - Positive
- N - N - Derived
613/354 Set Resistive Brake Contact Delay
- N N N N PM Motor only
1333 Set Rotary Motor Damping Coefficient
- N N N N Rotary Motor only
2312 Set Rotary Motor Fan Cooling Derating
- N N N N Rotary Motor only
2311 Set Rotary Motor Fan Cooling Speed
- N N N N Rotary Motor only
1330 Set Rotary Motor Inertia
- N Y Y Y Rotary Motor only
1332 Set Rotary Motor Max Speed
- Y Y Y Y Rotary Motor only
765 Set Safe Torque Off Action
- N N N N 0-Enum
1 = Current Decel Disable (F/N)
2 = Ramped Decel Disable (FV/N) 128 = DC Injection Brake
(FPVT/N) 129 = AC Injection Brake (FPVT/N)
629 Set Shutdown Action N - N N N N O-Enum
1 = Drop DC Bus (FPVT/N)
370 Set Skip Speed 1
- Y - - -
371 Set Skip Speed 2
- Y - - -
372 Set Skip Speed 3
- N - - -
373 Set Skip Speed Band
- Y - - -
833 Set SLAT Configuration
- - - Y -
834 Set SLAT Set Point
- - - Y -
835 Set SLAT Time Delay
- - - Y -
610 Set Stopping Action
- R R R R O-Enum
1 = Current Decel Disable (F/Y) V26/V27 2 = Ramped Decel
Disable (FV/N)
3 = Current Decel Hold (PV/Y) 4 = Ramped Decel Hold (V/N)
128 = DC Injection Brake (FPVT/N) 129 = AC Injection Brake
(FPVT/N)
