Allen-Bradley PowerFlex 755 Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 139
ID Access Rule Attribute Name B E F P V T Conditional Implementation
367 Get Acceleration Fine Command - - - Y Y Y
485 Set Acceleration Limit - - Y Y Y Y
482 Get Acceleration Reference - - - Y Y Y
481 Set Acceleration Trim - - - N N N
836 Set Adaptive Tuning Configuration - - - Y Y Y V26/V27
844 Get Adaptive Tuning Gain Scaling Factor - - - Y Y Y V26/V27
732/267 Get Analog Input 1 N - N N N N
733/268 Get Analog Input 2 N - N N N N
734 Set Analog Output 1 N - N N N N
735 Set Analog Output 2 N - N N N N
873 Set Auto Sag Configuration - - N N N N V26/V27
874 Set Auto Sag Slip Increment - - N N N N V26/V27
875 Set Auto Sag Slip Time Limit - - N N N N V26/V27
876 Set Auto Sag Start - - N N N N V26/V27
19 Set Axis Features R R R R R R O-Bits
0: Fine Interpolation (Y)
1: Registration Auto-rearm (Y)
2: Alarm Log (Y)
5: Hookup Test (Y)
6: Commutation Test (Y)
7: Motor Test (Y)
8: Inertia Test (Y)
9: Sensorless Control (N)
10: Drive Scaling (N) Vxx
11: Ext. Event Block (N) Vxx
12: Integer Cmd. Pos. (N) Vxx
13: Ext. Motor Test (N) V29
14: Control Mode Change (N) V26/V27
15: Feedback Mode Change (N) Vxx
16: Pass Bus Status (Y) V26/V27
17: Pass Bus Unload (Y) V26/V27
18: Ext. Speed for SPM (N) V29
19: Ext. Speed for IPM (Y) V29
986 Get Axis Safety Data A - - Y Y Y Y V31
987 Get Axis Safety Data B - - Y Y Y Y V31
763 Get Axis Safety Faults - Y Y Y Y Y V24
985 Get Axis Safety Faults - RA - Y Y Y Y Y V31
760 Get Axis Safety State - Y Y Y Y Y V24
761 Get Axis Safety Status - Y Y Y Y Y V24
984 Get Axis Safety Status - RA - Y Y Y Y Y V31
825 Set Backlash Compensation Window - - - Y - -
593 Set Brake Prove Ramp Time - - N N N N V26/V27
594 Set Brake Slip Tolerance - - Y Y Y Y V26/V27
592 Set Brake Test Torque - - Y Y Y Y V26/V27

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
