Allen-Bradley PowerFlex 755 Reference Manual

Interpret the Attribute Tables
Chapter 3
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 149
ID Access Rule Attribute Name B E F P V T Conditional Implementation
618 Set Connection Loss Stopping Action - - Y Y Y Y O-Enum V31
1 = Current Decel Disable (F/Y)
2 = Ramped Decel Disable (FV/Y)
3 = Current Decel Hold (PV/N)
4 = Ramped Decel Hold (V/N)
637 Get Converter Capacity N - N N N N
2337 Get Converter Output Capacity 1 N - N N N N Vxx
2357 Get Converter Output Capacity 2 N - N N N N Vxx
605 Get Converter Output Current N - N N N N V26/V27
2330 Get Converter Output Current 1 N - N N N N Vxx
2350 Get Converter Output Current 2 N - N N N N Vxx
606 Get Converter Output Power N - N N N N V26/V27
2331 Get Converter Output Power 1 N - N N N N Vxx
2351 Get Converter Output Power 2 N - N N N N Vxx
2332 Get Converter Output Rated Current 1 N - N N N N Vxx
2352 Get Converter Output Rated Current 2 N - N N N N Vxx
2333 Get Converter Output Rated Power 1 N - N N N N Vxx
2353 Get Converter Output Rated Power 2 N - N N N N Vxx
840 Set Current Disturbance - - - N N N
527 Get Current Error - - - Y Y Y
529 Get Current Feedback - - - Y Y Y
522 Get Current Limit Source - - Y Y Y Y (F/V29)
524 Get Current Reference - - - Y Y Y
553 Set Current Vector Limit - - Y Y Y Y
2334 Get DC Bus Output Voltage 1 N - N N N N Vxx
2354 Get DC Bus Output Voltage 2 N - N N N N Vxx
742 Get DC Bus Output Voltage Reference N - N N N N Vxx
2336 Get DC Bus Output Voltage Reference 1 N - N N N N Vxx
2356 Get DC Bus Output Voltage Reference 2 N - N N N N Vxx
870 Set DC Injection Brake Current - - N N N N
872 Set DC Injection Brake Time - - N N N N
486 Set Deceleration Limit - - N Y Y N
730 Get Digital Inputs N - N N N N
731 Set Digital Outputs N - N N N N
1435 Set Feedback 1 Accel Filter Bandwidth - Y - Y Y Y
2404 Set Feedback 1 Accel Filter Taps - Y - Y Y Y
2405 Set Feedback 1 Battery Absolute - N - N N N TM
1421 Set Feedback 1 Data Code - N - N N N TP,SS
1420 Set Feedback 1 Data Length - N - N N N TP,SS

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
