Allen-Bradley PowerFlex 755 Reference Manual

Chapter 3
Interpret the Attribute Tables
156 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
ID Access Rule Attribute Name B E F P V T Conditional Implementation
1376 Set Actuator Diameter N N N N N DScale
1377 Set Actuator Diameter Unit N N N N N DScale
1374 Set Actuator Lead N N N N N DScale
1375 Set Actuator Lead Unit N N N N N DScale
1373 Set Actuator Type N N N N N DScale
732/267 Get Analog Input 1 B B N N N N
733/268 Get Analog Input 2 B B N N N N
734 Set Analog Output 1 B B N N N N
735 Set Analog Output 2 B B N N N N
30 Set Axis Configuration R R R R R O-Enum
0 = Feedback Only (Y)
1 = Frequency Control (N)
2 = Position Loop (Y)
3 = Velocity Loop (Y)
4 = Torque Loop (Y)
19 Set Axis Features R R R R R O-Bits
0 = Fine Interpolation (Y)
1 = Registration Auto-rearm (Y)
2 = Alarm Log (Y)
5 = Hookup Test (Y)
6 = Commutation Test (Y)
7 = Motor Test (N)
8 = Inertia Test (Y)
9 = Sensorless Control (N)
763 Get Axis Safety Faults O O O O Y
760 Get Axis Safety State O O O O Y
761 Get Axis Safety Status O O O O Y
825 Set Backlash Compensation Window - - Y - -
638/262 Get Bus Regulator Capacity - N Y Y Y
659 Get CIP Axis Alarms Y N Y Y Y
904 Get CIP Axis Alarms - RA Y N Y Y Y
563 Set Commutation Polarity - - Y Y Y PM Motor only
562 Set Commutation Self-Sensing Current - - Y Y Y PM Motor only O-Value = 100
637 Get Converter Capacity - N Y Y Y
840 Set Current Disturbance - - N N N
527 Get Current Error - - Y Y Y
529 Get Current Feedback - - Y Y Y
522 Get Current Limit Source - - Y Y Y
524 Get Current Reference - - Y Y Y
553 Set Current Vector Limit - N N N N
870 Set DC Injection Brake Current - N N N N Ind Motor only
872 Set DC Injection Brake Time - N N N N Ind Motor only
486 Set Deceleration Limit - N Y Y N

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
