Allen-Bradley PowerFlex 755 Reference Manual

Chapter 4
CIP Axis Attributes
370 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
Bit Name Description
2...31 Reserved
Master Position Filter Bandwidth
Usage Access Data
Type
Default Min Max Semantics of Values
Required - E
PV only
Set/
SSV
REAL 0
1/(4*CUP)
0 1000
(1)
1/CUP
Hertz
Valid when Master Position
Filter is enabled.
A value of 0 disables the filter.
CUP = Coarse Update Period
(1)
Minimum Range limits based on Coarse Update Period are ultimately enforced
for Master Position Filter Bandwidth attribute by clamping to limit rather than
generating a value out of range error. Only if the value is outside the fixed
Min/Max limits is an out of range error given. This was done to avoid
implementing complex range limit code based on the Coarse Update Period in the
Logix Designer application.
The Master Position Filter Bandwidth attribute controls the activity of the
single-poll low-pass filter that filters the specified master axis position input to the
slave's gearing or position camming operation. When enabled, this filter has the
effect of smoothing out the actual position signal from the master axis, and thus
smoothing out the corresponding motion of the slave axis. The trade-off for
smoothness is an increase in lag time between the response of the slave axis to
changes in motion of the master.
If the Master Position Filter is disabled, the Master Position Filter Bandwidth has
no effect.

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
