Allen-Bradley PowerFlex 755 Reference Manual

CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 411
Actuator Lead Unit
Usage Access Data
Type
Default Min Max Semantics of Values
Required - All Set/GSV USINT 0 - - Enumeration
0 = mm/Rev
1 = Inch/Rev
2...255 = Reserved
The Actuator Lead Unit attribute indicates the units of the Actuator Lead
attribute.
Actuator Diameter
Usage Access Data
Type
Default Min Max Semantics of Values
Required - All Set/GSV REAL 1 0+
Actuator Diameter Units
The Actuator Diameter attribute is a floating point value that represents the
diameter of the pulley, sprocket, or pinion used to convert rotary motion into
tangential linear displacement of the load. The Actuator Diameter is internally
converted to circumference of the pulley, sprocket, or pinion to determine the
amount of tangential displacement per revolution.
Actuator Diameter Unit
Usage Access Data
Type
Default Min Max Semantics of Values
Required - All Set/GSV USINT 0 - - Enumeration
0 = mm
1 = Inch
2...255 = Reserved
The Actuator Diameter Unit attribute is a value that indicates the units of the
Actuator Diameter attribute.
See also
Motor Attributes on page 57
General Motor Attributes on page 389
General Permanent Magnet Motor Attributes on page 396
General Rotary Motor Attributes on page 399
General Linear Motor Attributes on page 388

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
