CIP Axis Attributes
Chapter 4
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 459
Array
Index
Rule Exception Description
21 BD Converter Thermal Overload UL
Converter thermal model or I
2
T overload value has
exceeded its user-defined thermal capacity given by the
Converter Thermal Overload User Limit.
22 BD Converter AC Power Loss
Multiple AC phases have been lost on the AC line to the
converter. When associated with an external converter in a
Shared AC/DC or Shared DC bus configuration, the AC Power
Loss condition detected by the converter can be conveyed
using the CIP Motion connection's Control Status element.
Generally, this exception is not asserted unless the device's
power structure is enabled.
23 BD Converter AC Single Phase Loss
One AC phase have been lost on the AC line to the
converter.
24 BD Converter AC Phase Short
A short has been detected between an AC phase and
another AC phase or ground.
25 BD Converter Pre-Charge Failure
A problem has been detected in the pre-charge circuitry of
the converter preventing the DC Bus from charging to an
acceptable voltage level.
26
--Reserved-- -
27 BD
Bus Regulator Overtemperature
FL
Bus Regulator temperature has exceeded its factory set
temperature limit given by the Bus Regulator
Overtemperature Factory Limit.
28 BD
Bus Regulator Overtemperature
UL
Bus Regulator temperature has exceeded the user-defined
temperature limit given by the Bus Regulator
Overtemperature User Limit.
29 BD
Bus Regulator Thermal
Overload FL
Bus Regulator thermal model or I
2
T overload value has
exceeded its factory set thermal capacity limit given by the
Bus Regulator Thermal Overload Factory Limit.
30 BD
Bus Regulator Thermal
Overload UL
Bus Regulator thermal model or I
2
T overload value has
exceeded its user-defined thermal capacity given by the
Bus Regulator Thermal Overload User Limit.
31 BD Bus Regulator Failure
The bus regulator (shunt) module in a multi-axis system
has a failed.
32 BD Bus Capacitor Module Failure The bus capacitor module failed.
33 BD Bus Undervoltage FL
DC Bus voltage level is below the factory set limit given by
the Bus Undervoltage Factory Limit.
34 BD Bus Undervoltage UL
DC Bus voltage level is below user-defined limit given by
the Bus Undervoltage User Limit.
35 BD Bus Overvoltage FL
DC Bus voltage level is above the factory set limit given by
the Bus Overvoltage Factory Limit.
36 BD Bus Overvoltage UL
DC Bus voltage level is above user-defined limit given by
the Bus Overvoltage User Limit.
37 BD Bus Power Loss
DC Bus voltage level is below the Bus Power Loss Threshold
for more than the timeout period specified by the Bus
Power Loss Time value.
38 BD Bus Power Fuse Blown DC bus power loss due to blown fuse.
