Module Configuration Attributes
Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018 479
• "AC/DC Non-Regenerative" represents the class of devices that convert AC
input power to DC output power. They do not have the capability to
transfer energy back to the AC main supply.
• "AC/DC Regenerative" represents the class of devices that convert power
between AC and DC sources. They have the capability to transfer energy
bidirectionally between an AC main supply and DC bus in both directions.
These devices provide active control to regulate energy transfer between AC
main and DC bus.
• "DC/DC Non-Regenerative" represents the class of devices that convert
DC input power to DC output power. They do not have the capability to
transfer energy back to the primary DC bus supply.
• "DC/DC Regenerative" represents the Class of devices that convert power
between two DC sources. They have the capability to transfer energy
between a primary DC bus and a secondary DC bus in both directions.
These devices may provide active control to regulate energy transfer
between the primary and secondary buses.
DC Bus Output Voltage Set Point
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
REAL 0 0
Volts
Sets the reference voltage used to actively regulate the DC Output Bus Voltage of
the converter when in the Running state.
Shunt Regulator Resistor Type
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
USINT 0 - - Enumeration:
0 = Internal
1 = External
2-255 = (reserved)
This attribute defines whether an Internal or External Shunt resistor is used.
External Shunt Regulator ID
Usage Access T Data Type Default Min Max Semantics of Values
Optional - BD Set
INT -1 -1 32767 -1 = None
0 = Custom
1-32767 = Shunt Regulator ID
