Chapter 3
Interpret the Attribute Tables
88 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
Column Heading Description
Device Control Codes (mode)
The following identifiers are used for Device Function Codes:
• Required - All = All Control Modes
• Optional - All = All Control Modes
If applicable only to specific implementations, the following codes will be used to
denote when they apply:
• Individual codes:
B = Bus Power Converters (No Control Mode, No Control Method)
E = Encoder present, Feedback Only (No Control Mode, No Control Method)
F= Frequency Control (Velocity Control Mode, Frequency Control Method)
P = Position Loop (Position Control Mode, Closed Loop Vector Control Method)
V = Velocity Control Loop (Velocity Control Mode, Closed Loop Vector Control
Method)
T = Torque Control Loop (Torque Control Mode, Closed Loop Vector Control
Method)
C\D = Identifies the attributes that have a matching, or replicated attributes in
the associated device/drive.
• Combination codes:
B = All device functions using No Control Method -Feedback Only (B, E)
O = All device functions using Open Loop Control Methods -Frequency Control
(F)
C = All device functions using Closed Loop Control Methods (P, V, T)
D = All device functions using Control Methods (P, V, T, F)
• Encoderless/sensorless drive codes:
E Encoder present. (N, P ,V ,T with Feedback device present.)
!E Encoderless/sensorless control, feedback device is not present.(Closed Loop
Sensorless Vector and Frequency Controlled)

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
