Chapter 3
Interpret the Attribute Tables
96 Rockwell Automation Publication MOTION-RM003I-EN-P - February 2018
• B – Bus Power Converters (No Control Mode, No Control Method)
• E – Encoder, Feedback Only (No Control Mode, No Control Method)
• P – Position Loop (Position Control Mode, Closed Loop Vector Control
Method)
• V – Velocity Loop (Velocity Control Mode, Closed Loop Vector Control
Method)
• T – Torque Loop (Torque Control Mode, Closed Loop Vector Control
Method)
• F – Frequency Control (Velocity Control Mode, Frequency Control
Method)
The C/D column states whether the attribute is replicated in the drive.
Attr. ID Access
Rule
Tag Attribute Name B E F P V T C/D Conditional
Implementation
483/138 Get T Acceleration Feedback - R - R R R Yes
452 Get T Acceleration Feedforward Command - - - R R - Yes
460/216 Set T Acceleration Feedforward Gain - - - R R - Yes
367 Get T Acceleration Fine Command - - - O O O Yes
485 Set Acceleration Limit - - O O O O Yes
482 Get T Acceleration Reference - - - O O O Yes
481 Set T Acceleration Trim - - - O O O Yes
53 Get T Actual Acceleration - R R R R R
48 Get T Actual Position - R R R R R
52 Get T Actual Velocity - R R R R R
1376 Set Actuator Diameter - C C C C C Yes
(R) Controller only attribute,
Motion Scaling Configuration
set to Controller Scaling;
(O) Drive replicated attribute,
Motion Scaling Configuration
set to Drive Scaling
1377 Set Actuator Diameter Unit - C C C C C Yes
(R) Controller only attribute,
Motion Scaling Configuration
set to Controller Scaling;
(O) Drive replicated attribute,
Motion Scaling Configuration
set to Drive Scaling
1374 Set Actuator Lead - C C C C C Yes
(R) Controller only attribute,
Motion Scaling Configuration
set to Controller Scaling;
(O) Drive replicated attribute,
Motion Scaling Configuration
set to Drive Scaling

Allen-Bradley PowerFlex 755 Specifications

General

Category	AC Drive
Amperage	2.2…1470 A
Output Voltage	0 to Input Voltage
Output Current	2.2…1470 A
Enclosure	IP20, IP30, IP54
Communications	EtherNet/IP, ControlNet, DeviceNet
I/O	Digital, Analog, Encoder, Relay
Safety	Safe Speed Monitor
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overload, Short Circuit, Ground Fault, Overtemperature
Operating Temperature	-10°C to 50°C (14°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5…95% noncondensing
Altitude	Up to 1000m (3300ft) without derating
Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC, 690V AC
Control Method	Sensorless Vector
