468 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
PortFa1_13Connected BOOL Decimal LinkStatus:13
PortFa1_14Connected BOOL Decimal LinkStatus:14
PortFa1_15Connected BOOL Decimal LinkStatus:15
PortFa1_16Connected BOOL Decimal LinkStatus:16
PortGi1_1Connected BOOL Decimal LinkStatus:19
PortGi1_2Connected BOOL Decimal LinkStatus:20
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortFa1_6UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
PortFa1_7UnauthorizedDevice BOOL Decimal UnauthorizedDevice:7
PortFa1_8UnauthorizedDevice BOOL Decimal UnauthorizedDevice:8
PortFa1_9UnauthorizedDevice BOOL Decimal UnauthorizedDevice:9
PortFa1_10UnauthorizedDevice BOOL Decimal UnauthorizedDevice:10
PortFa1_11UnauthorizedDevice BOOL Decimal UnauthorizedDevice:11
PortFa1_12UnauthorizedDevice BOOL Decimal UnauthorizedDevice:12
PortFa1_13UnauthorizedDevice BOOL Decimal UnauthorizedDevice:13
PortFa1_14UnauthorizedDevice BOOL Decimal UnauthorizedDevice:14
PortFa1_15UnauthorizedDevice BOOL Decimal UnauthorizedDevice:15
PortFa1_16UnauthorizedDevice BOOL Decimal UnauthorizedDevice:16
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:19
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:20
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortFa1_1Threshold BOOL Decimal ThresholdExceeded:1
PortFa1_2Threshold BOOL Decimal ThresholdExceeded:2
PortFa1_3Threshold BOOL Decimal ThresholdExceeded:3
PortFa1_4Threshold BOOL Decimal ThresholdExceeded:4
PortFa1_5Threshold BOOL Decimal ThresholdExceeded:5
PortFa1_6Threshold BOOL Decimal ThresholdExceeded:6
PortFa1_7Threshold BOOL Decimal ThresholdExceeded:7
PortFa1_8Threshold BOOL Decimal ThresholdExceeded:8
PortFa1_9Threshold BOOL Decimal ThresholdExceeded:9
PortFa1_10Threshold BOOL Decimal ThresholdExceeded:10
PortFa1_11Threshold BOOL Decimal ThresholdExceeded:11
PortFa1_12Threshold BOOL Decimal ThresholdExceeded:12
Table 150 - Input Data Type (18-port Gb switches) (continued)
AB:STRATIX_5700_18PORT_GB_MANAGED:I:0
Member Name Type Default
Display Style
Valid Values
