Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 469
Data Types Appendix A
PortFa1_13Threshold BOOL Decimal ThresholdExceeded:13
PortFa1_14Threshold BOOL Decimal ThresholdExceeded:14
PortFa1_15Threshold BOOL Decimal ThresholdExceeded:15
PortFa1_16Threshold BOOL Decimal ThresholdExceeded:16
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:19
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:20
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortFa1_5Utilization SINT Decimal
PortFa1_6Utilization SINT Decimal
PortFa1_7Utilization SINT Decimal
PortFa1_8Utilization SINT Decimal
PortFa1_9Utilization SINT Decimal
PortFa1_10Utilization SINT Decimal
PortFa1_11Utilization SINT Decimal
PortFa1_12Utilization SINT Decimal
PortFa1_13Utilization SINT Decimal
PortFa1_14Utilization SINT Decimal
PortFa1_15Utilization SINT Decimal
PortFa1_16Utilization SINT Decimal
PortGi1_1Utilization SINT Decimal
PortGi1_2Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 151 - Output Data Type (18-port Gb switches)
AB:STRATIX_5700_20PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortFa1_5Disable BOOL Decimal DisablePort:5
Table 150 - Input Data Type (18-port Gb switches) (continued)
AB:STRATIX_5700_18PORT_GB_MANAGED:I:0
Member Name Type Default
Display Style
Valid Values
