Allen-Bradley Stratix 8000 Installation Instructions

Rockwell Automation Publication 1783-IN012A-EN-P - July 2017 17
Stratix 8000 and 8300 Ethernet Managed Switches
Specifications
Stratix 8000 and 8300 Switches
Attribute 1783-MS06T, 1783-MS10T, 1783-RMS06T, 1783-RMS10T
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-40 °C < Ta < +60 °C (-40 °F < Ta < +140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure type rating None (open-style)
Power input 2 A max, 18…60V DC, CL 2/SELV
Alarm relay 1A max, 30V DC max, CL 2/SELV
Isolation voltage
75 V (continuous), basic insulation type, power to ground, power to network channels, and power to alarm.
No isolation between individual Ethernet ports
No isolation between Console port and system
Wire size, Ethernet connections
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to
ISO/IEC 24702
Wire size, power and alarm connections 0.5… 0.8 mm
2
(20…18 AWG) solid or stranded copper wire rated at 90 °C (194 °F) or greater, 1.2 mm (3/64 in.) insulation, max
Wire size, ground connection 3.3…5.3 mm
2
(12…10 AWG) solid or stranded copper wire rated at 75 °C (167 °F) or greater
Screw torque, power and alarm terminals 0.23 N•m (2.0 in•lb)
Screw torque, ground terminals 0.96 N•m (8.5 in•lb)
Pilot duty rating Alarm not rated
North American temp code T4
ATEX temp code T4
Stratix 8000 and 8300 Expansion Modules
Attribute 1783-MX04E 1783-MX04T04E
1783-MX08T 1783-MX08F 1783-MX04S 1783-MX08S
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
-40 °C < Ta < +60 °C (-40 °F < Ta < +140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure type rating None (open-style)
Backplane power 3.3V DC @ 0.94 A 3.3V DC @ 1.08 A 3.3V DC, 1.7 A max 3.3V DC, 3.6A max 3.3V DC, 2.5 A max 3.3V DC, 4.0 A max
PoE power, max 48/54V DC, 2.5 A 48/54V DC, 2.4 A —
Isolation voltage
60V (continuous), basic insulation type,
expansion backplane to network ports,
expansion backplane to power ports, and
power ports to network ports. No isolation
between individual network ports.
75V (continuous),
basic insulation type,
expansion backplane to
network channels. No
isolation between
individual Ethernet ports.
—
Wire size, Ethernet connections
RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to
ISO/IEC 24702
Screw torque, PoE power 0.23 N•m (2.0 in•lb) —
North American temp code T4
ATEX temp code T4
